S3F9454BZZ Samsung
8-BIT CMOS MICROCONTROLLER
ข้อมูลแบบเข้าใจง่าย (Specification)
Production Status: Mass Production
Application: HA/Consumer
Product Type: S3C9(KS86) Series
ROM(KB): 4
RAM: 208
I/O Pins: 18
Timer/Counters: BT, 8TC
ADC (BitxCh): 10x9
PWM(BitxCh): 8x1
Max. OSC.Freq. (MHz): 10
Total Pins: 16, 20
Other Features: B/C With 10Bit ADC(Main)
Temperature: -25~85
Package: 16DIP, 16SOP, 16TSSOP, 20DIP, 20SOP, 20SSOP
Features
CPU
- SAM88RCRI CPU core
- The SAM88RCRI core is low-end version of the current SAM87 core.
Memory
- 4-Kbyte internal program memory
- 208-byte general purpose register area
Instruction Set
- 41 instructions
- The SAM88RCRI core provides all the SAM87 core instruction except the word-oriented instruction, multiplication, division, and some one-byte instruction.
Instruction Execution Time
- 400 ns at 10 MHz fOSC (minimum)
Interrupts
- 4 interrupt sources with one vectors
- One interrupt level
General I/O
- Three I/O ports (Max 18 pins)
- Bit programmable ports
8-bit High-speed PWM
- 8-bit PWM 1-ch (Max: 156 kHz)
- 6-bit base + 2-bit extension
Built-in Reset Circuit
- Low voltage detector for safe Reset
Timer/Counters
- One 8-bit basic timer for watchdog function
- One 8-bit timer/counter with time interval modes
A/D Converter (Optional)
- Nine analog input pins (MAX)
- 10-bit conversion resolution
Oscillation Frequency
- 1 MHz to 10 MHz external crystal oscillator
- Maximum 10 MHz CPU clock
- Internal RC: 3.2 MHz (typ.), 0.5 MHz (typ.) in VDD = 5 V
Operating Temperature Range
- –25℃ to + 85℃
Operating Voltage Range
- 2.0 V to 5.5 V (LVR disable)
- LVR to 5.5V (LVR enable)
Smart Option
Package Types
- S3C9454B/F9454B:
- 20-SSOP-225
- 20-DIP-300A
- 20-SOP-375
- 16-SOP-BD300-SG
- 16-DIP-300A
- 16-SSOP-BD44
