70HFR120 Rectifiers Brand Vishay Reviews

70HFR120 VISHAY
Rectifiers 1200 Volt 70 Amp

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 70HFR120
Brand : Vishay
Description : Rectifiers 1200 Volt 70 Amp
Package : DO-5

Configuration: Single

Reverse Voltage: 1200 V

Forward Voltage Drop: 1.35 V at 220 A

Forward Continuous Current: 70 A

Max Surge Current: 1250 A

Reverse Current IR: 9000 uA

Mounting Style: Stud

Packaging: Bulk

Maximum Operating Temperature: + 180 C

Minimum Operating Temperature: - 65 C

FEATURES

- High surge current capability

- Designed for a wide range of applications

- Stud cathode and stud anode version

- Leaded version available

- Types up to 1600 V VRRM

- Designed and qualified for industrial level

TYPICAL APPLICATIONS

- Converters

- Power supplies

- Machine tool controls

- Battery charges

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

28C04A-25I/P EEPROM Brand MICROCHIP Reviews

28C04A-25I/P MICROCHIP
4K (512 x 8) CMOS EEPROM

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 28C04A-25I/P

Brand : MICROCHIP

Description : 4K (512 x 8) CMOS EEPROM

Package : DIP-24

FEATURES

• Fast Read Access Time—150 ns

• CMOS Technology for Low Power Dissipation

- 30 mA Active

- 100 µA Standby

• Fast Byte Write Time—200 µs or 1 ms

• Data Retention >200 years

• Endurance - Minimum 104 Erase/Write Cycles

- Automatic Write Operation

- Internal Control Timer

- Auto-Clear Before Write Operation

- On-Chip Address and Data Latches

• Data Polling

• Chip Clear Operation

• Enhanced Data Protection

- VCC Detector

- Pulse Filter

- Write Inhibit

• 5-Volt-Only Operation

• Organized 512x8 JEDEC standard pinout

- 24-pin Dual-In-Line Package

- 32-pin PLCC Package

• Available for Extended Temperature Ranges:

- Commercial: 0°C to +70°C

- Industrial: -40°C to +85°C

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

16RIA120M SCR Brand IR Reviews

16RIA120M IR - SCR 1200V 35A

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 16RIA120M
Brand : IR
Description : SCR 1200V 35A
Package : TO-208AA, TO-48-3, Stud

Voltage - Off State : 1200V

Voltage - Gate Trigger (Vgt) (Max) : 2V

Current - Gate Trigger (Igt) (Max): 60mA

Voltage - On State (Vtm) (Max): 1.75V

Current - On State (It (AV)) (Max) : 16A

Current - On State (It (RMS)) (Max) : 35A

Current - Hold (Ih) (Max): 130mA

Current - Off State (Max): 10mA

Current - Non Rep. Surge 50, 60Hz (Itsm): 285A, 300A

SCR Type: Standard Recovery

Operating Temperature: -65°C ~ 125°C

Mounting Type: Chassis, Stud Mount

FEATURES

- Improved glass passivation for high reliability and exceptional stability at high temperature

- High dI/dt and dV/dt capabilities

- Standard package

- Low thermal resistance

- Metric threads version available

- Types up to 1200 V VDRM/VRRM

- Designed and qualified for industrial and consumer level

TYPICAL APPLICATIONS

- Medium power switching

- Phase control applications

- Can be supplied to meet stringent military, aerospace and other high reliability requirements.

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

5KP20CA TVS Diodes Brand Littelfuse Reviews

5KP20CA Littelfuse - TVS Diodes - Transient Voltage Suppressors 20Vso 15VAC 154A

ข้อมูลแบบเข้าใจง่าย (Specification)
Part : 5KP20CA
Brand : Littelfuse
Description : TVS Diodes - Transient Voltage Suppressors 20Vso 15VAC 154A

Polarity: Bidirectional

Operating Voltage: 20 V

Breakdown Voltage: 22.2 V

Clamping Voltage: 32.4 V

Peak Surge Current: 154 A

Series: 5KP

Minimum Operating Temperature: - 55 C

Maximum Operating Temperature: + 175 C

Dimensions: 9.1 mm Dia. x 9.1 mm L

Mounting Style: Through Hole

Packaging: Reel

Peak Pulse Power Dissipation: kW

Features

Halogen-Free and RoHS compliant

Typical maximum temperature coefficient ΔVBR = 0.1% × VBR@25°C

Glass passivated junction

5000W peak pulse capability at 10×1000μs waveform, repetition rate (duty cycles):0.01%

Fast response time: typically less than 1.0ps from 0 Volts to BV min

Excellent clamping capability

Low incremental surge resistance

Typical IR less than 2μA above 12V

High temperature soldering guaranteed: 265°C./10 seconds/ 0.375”,(9.5mm) lead length, 51bs., (2.3kg) tension

Plastic package has Underwriters Laboratory Flammability classification 94V-O

Matte Tin Lead–free plated

Applications

TVS devices are ideal for the protection of I/O interfaces, VCC bus and other vulnerable circuits used in telecom, computer, industrial and consumer electronic applications.

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

2SK3565 Transistor Brand Toshiba Reviews

2SK3565 Toshiba - Field Effect Transistor Silicon N Channel MOS

ข้อมูลแบบเข้าใจง่าย (Specification)
Part : 2SK3565
Brand : Toshiba
Description : Field Effect Transistor Silicon N Channel MOS

Package : TO-3

Switching Regulator Applications

Contact Us :
rtbselec@gmail.com
http://aecelec.blogspot.com/
http://www.Buy-Electronic.net/
Skype : Ohomodules

2SD388 Transistors Brand NEC Reviews

2SD388 NEC
Silicon NPN Power Transistors

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 2SD388
Brand : NEC
Description : Silicon NPN Power Transistors
Package : TO-3

·With TO-3 package

·High power dissipation

APPLICATIONS
- For use in power amplifier applications

Contact Us :
rtbselec@gmail.com
http://aecelec.blogspot.com/
http://www.Buy-Electronic.net/
Skype : Ohomodules

2SC2608 Silicon NPN Power Transistors Brand SANKEN Reviews

2SC2608 SANKEN
Silicon NPN Power Transistors

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 2SC2608

Brand : SANKEN

Description : Silicon NPN Power Transistors

Package : TO-3

With TO-3 package

·Complement to type 2SA1117

·High power dissipation

APPLICATIONS

- For power amplifier applications

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

2SC2581 TRANSISTOR BRAND WINGS REVIEWS

2SC2581 WINGS - AUDIO POWER AMPLIFIER, DC TO DC CONVERTER(NPN)

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 2SC2581

Brand : WINGS

Description : AUDIO POWER AMPLIFIER, DC TO DC CONVERTER(NPN)

Package : TO-3

FEATURES
- High Current Capability
- High Power Dissipation
- Complementary to 2SA1106

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

2SB541A TRANSISTOR BRAND NEC REVIEWS

2SB541A NEC - SILICON POWER TRANSISTOR

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 2SB541A
Brand : NEC
Description : SILICON POWER TRANSISTOR
Package : TO-3

APPLICATIONS

- For power switching and general purpose applications

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

2SA1720 TRANSISTOR BRAND NEC REVIEWS

2SA1720 NEC - PNP SILICON EPITAXIAL TRANSISTOR (DARLINGTON CONNECTION) FOR HIGH-SPEED SWITCHING

ข้อมูลแบบเข้าใจง่าย (Specification)
Part : 2SA1720
Brand : NEC
Description : PNP SILICON EPITAXIAL TRANSISTOR (DARLINGTON CONNECTION)
FOR HIGH-SPEED SWITCHING
Package : TO-220

FEATURES

- Mold package that does not require an insulating board or insulation bushing

- On-chip C-to-E reverse diode

- Fast switching speed

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

2SA1015 TRANSISTOR BRAND TOSHIBA REVIEWS

2SA1015 TOSHIBA - Transistor for low frequency small-signal amplification

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 2SA1015
Brand : TOSHIBA
Description : Transistor for low frequency small-signal amplification
Package : TO-92

Audio Frequency Amplifier Applications Low Noise Amplifier Applications

Absolute Maximum Ratings

Characteristics                 Symbol       Rating         Unit

Collector Current                     IC            -0.15             A

Collector-emitter voltage        VCEO    -50            V

Electrical Characteristics

DC Current Gain hFE (Max) hFE 400

DC Current Gain hFE (Min) hFE 70

Collector Emitter Saturation Voltage (Max) VCE(sat) -0.3 V

Contact Us :
rtbselec@gmail.com
http://aecelec.blogspot.com/
http://www.Buy-Electronic.net/
Skype : Ohomodules

2N3866 Bipolar Transistors BJT Brand MEV Reviews

2N3866 MEVBipolar Transistors - BJT NPN VHF/UHF AM

ข้อมูลแบบเข้าใจง่าย (Specification)
Part : 2N3866
Brand : MEV
Description : Bipolar Transistors - BJT NPN VHF/UHF AM
Package : TO-39

Transistor Polarity: NPN

Collector- Base Voltage VCBO: 55 V

Collector- Emitter Voltage VCEO Max: 30 V

Emitter- Base Voltage VEBO: 3.5 V

Collector-Emitter Saturation Voltage: 1 V

Maximum DC Collector Current: 0.4 A

Gain Bandwidth Product fT: 500 MHz

Maximum Operating Temperature: + 150 C

Mounting Style: Through Hole

DC Collector/Base Gain hfe Min: 10

Maximum Power Dissipation: 5 W

Minimum Operating Temperature: - 65 C

APPLICATIONS

- The transistors are intended for use in output, driver or pre-driver stages in VHF and UHF equipment.

Contact Us :
rtbselec@gmail.com
http://aecelec.blogspot.com/
http://www.Buy-Electronic.net/
Skype : Ohomodules

1MBH15D-120 Molded IGBT Brand Fuji Reviews

1MBH15D-120 FUJI
Molded IGBT

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 1MBH15D-120
Brand : Fuji
Description : Molded IGBT
Package : TO-220

Features

- Small molded package

- Low power loss

- Soft switching with low switching surge and noise

- High reliability, high ruggedness (RBSOA, SCSOA etc.)

- Comprehensive line-up

Applications

- Inverter for Motor drive

- AC and DC Servo drive amplifier

- Uninterruptible power supply

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

1DI30A-060 TRANSISTOR Brand FUJI Reviews (Datasheet pdf)

1DI30A-060 FUJI
TRANSISTOR 30A 600V

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : 1DI30A-060

Brand : FUJI

Description :  TRANSISTOR 30A 600V

Package : Module

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

1.5KE36CA TVS Diodes Brand STMicroelectronics Reviews (datasheetd pdf)

1.5KE36CA STMicroelectronics
Transient Voltage Suppressors 1500W 36V

ข้อมูลแบบเข้าใจง่าย (Specification)
Part : 1.5KE36CA
Brand : STMicroelectronics
Description :  Transient Voltage Suppressors 1500W 36V
Package : DO-201

Operating Voltage: 30.8 V
Breakdown Voltage: 34.2 V
Clamping Voltage: 64.3 V
Peak Surge Current: 156 A
Series: 1.5KE36
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 175 C
Capacitance: 2500 pF
Dimensions: 5.3 mm Dia. x 9.5 mm L
Mounting Style: Through Hole

Peak Pulse Power Dissipation: 1.5 kW

Features

- Peak pulse power: 1500 W (10/1000 µs)

- Breakdown voltage range: From 6.8 V to 440 V

- Uni and bidirectional types

- Low clamping factor

- Fast response time

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

UC3708N Gate Drivers Brand Texas Instruments (datasheet pdf)

UC3708N Texas Instruments Gate Drivers Non-Inv High Speed Power Driver

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : UC3708N

Brand : TI

Description : Gate Drivers Non-Inv High Speed Power Driver

Package : DIP-8

Configuration: Non-Inverting

Number of Drivers: 2 Driver

Rise Time: 25 ns

Fall Time: 25 ns

Output Current: 3 A

Supply Voltage - Max: 35 V

Supply Voltage - Min: 10 V

Supply Current: 26 mA

Maximum Operating Temperature: + 70 C

Mounting Style: Through Hole

Package / Case: PDIP-8

Type: Non-Inverting

Minimum Operating Temperature: 0 C

Number of Outputs: 2

FEATURES

- High-Speed, Power MOSFET Compatible

- 3.0A Peak Current Totem Pole Output • Efficient High Frequency Operation

- 5 to 35V Operation • Low Cross-Conduction Current Spike

- 25ns Rise and Fall Times • Enable and Shutdown Functions

- 25ns Propagation Delays • Wide Input Voltage Range

- Thermal Shutdown and Under-Voltage • ESD Protection to 2kV Protection

จบแล้วนะครับสำหรับการรีวิวตัว UC3708N รอติตตามบทความถัดไปนะครับ

Contact Us :

rtbselec@gmail.com

http://aecelec.blogspot.com/

http://www.Buy-Electronic.net/

Skype : Ohomodules

Reviews UC3526AN Regulating Pulse Width Modulator Brand TI (datasheet pdf)

UC3526AN TI  Regulating Pulse Width Modulator

ข้อมูลแบบเข้าใจง่าย (Specification)

Part : UC3526AN

Brand : TI

Description : Regulating Pulse Width Modulator

Package : DIP-18

FEATURES

- Reduced Supply Current

- Oscillator Frequency to 600kHz

- Precision Band-Gap Reference

- 7 to 35V Operation

- Dual 200mA Source/Sink Outputs

- Minimum Output Cross-Conduction

- Double-Pulse Suppression Logic

- Under-Voltage Lockout

- Programmable Soft-Start

- Thermal Shutdown

- TTL/CMOS Compatible Logic Ports

- 5 Volt Operation (VIN = VC = VREF = 5.0V)
